CNC Nesting Machine ATC1325-S4

Specification

X Working Area	1300mm
Y Working Area	2500mm
Z Working Area	280mm
Table size	1380x2750mm
Traveling Positioning Accuracy	±0.05mm
Repositioning Positioning Accuracy	±0.05mm
Table Type	Vacuum table
Vacuum pump	5.5KW water vacuum pump
X,Y ,Z Structure	XY gear wheel, Z ball screw
Max. Power Consumption	≤20KW
Max. Rapid Travel Rate	45000mm/min
Max. Working Speed	25000mm/min
Spindle	24.5kw and 26.0kw air cooled spindle
Inverter	7.5kw
Spindle Speed	0-18000rpm/min
Driver& Motor	XY axis with 750w and Z aixis with 1.8kw servo motor,Z axis with Japan shimpo reducer
Command	G-code.u00.mmg*.plt

Features

1.ALL-WELDED STEEL BASE： The bed is made by CNC metalworking centers, which makes it possible to obtain high accuracy and quality when processing workpieces of any size. 2.STEEL PORTAL： Made of rectangular steel pipes and reinforced, it provides a high degree of rigidity, resistance to static and dynamic loads.Portals frame is made by CNC metalworking centers. Guaranteed high accuracy and quality better than the cheap lightweight aluminum portals. 3.SKEWED GEARS GEAR – RACK AXIS X –Y： The teeth in helical gears are loaded gradually as they enter the engagement zone, at least two pairs of teeth are always in engagement. These factors determine the smooth operation of the helical gearing, as well as the reduction of noise and additional dynamic loads in comparison with the spur gearing. 4.AUTO-TOOL CHANGE: With linear tool changer, constructed with world-class components, consistent high performance
